Cleanroom Steel Door/hermetic steel door

Product Features

• Door Frame: Made of 1.5 mm galvanized steel plate, integrally bent and welded, with powder-coated finish for durability. The frame surface is seamless and smooth after forming. The vertical frame is equipped with an embedded, removable sealing strip, ensuring reliable airtightness and convenient cleaning/maintenance. Standard wall depths (50 mm, 75 mm, 100 mm) meet cleanroom requirements by minimizing internal corners and steps.

• Door Leaf: Constructed with a buckle-structure assembly to ensure flatness, strength, and aesthetics. The bottom of the door leaf incorporates a retractable spring-loaded sealing system with a compression sealing strip, which automatically lowers during closing to enhance airtight performance.

• Vision Panel: Double-layer tempered glass, flush-mounted with the door surface, providing a smooth, modern appearance that is easy to clean and maintain.

• Optional Airtight Design: Gas-tight cleanroom door systems with supply-air sealing options can be provided upon request.

• Hardware: High-quality hardware with antibacterial electrostatic coating, reducing bacterial growth in medical and cleanroom environments.

Technical Specifications

• Door Leaf Thickness: 50 mm

• Door Leaf Steel Plate Thickness: 0.8 mm

• Door Frame Depth: 50 mm (other options: 75 mm / 100 mm)

• Door Frame Steel Plate Thickness: 1.5 mm

• Internal Core: High-density honeycomb paper

• Manual Push Force: < 80 N

• Single Door Size（Max）: 1300 × 3000 mm

• Double Door Size (Max): 3000 × 3000 mm

• Vision Panel Size: 200 × 800 mm (W × H), available in single-layer or double-layer glass

• Surface Finishes Available:

  • Electrostatic powder coating

  • Painted surface

  • PVC hot-coated wood grain film

Structure:
